| Screen Resolution |
360000 Pixels |
|---|---|
| LED BRANDLED |
KING LIGHT |
| LAMP MODEL |
SMD 1921 |
| LED Configuration |
1R1G1B |
| Pixel Pitch |
4.81 mm |
| Physical Density |
43403 PIXEL/M2 |
| MODULE SIZE |
288 x 288 mm |
| Module Resolution |
75 x 75 Dots |
| Drive Mode |
1/15S |
| Cabinet Configuration |
576mm x 576 mm x 85 mm |
| Cabinet Resolution |
120 x 120 Dots |
| cabinet weight |
9.8 kgs |
| Module quantity |
4 pcs |
| Material Of Cabinet |
Die cast aluminum alloy |
| color of cabinet |
black (can be changed free) |
| Brightness |
≥4000 cd/m2 |
| view angle |
120°(h),110°(v) |
| Gray scale |
≥16bits/4096 level |
| color capacity |
1.67 billion |
| Maximum power consumption |
500 W/m2 |
| Average power consumption |
200/m2 |
| Operating Power Source |
220V,50-60Hz |
| recieving card |
NOVA STAR , A5S-N |
| POWER SUPPLY BRAND |
RONGTRONIC |
| REFRESH RATE |
≥3840 Hz |
| Drive IC |
ICN 3153/SM 16380 |
| Service |
REAR |
| MODULE CAONNECTION |
SOLID CONNECTION |
| CONTROL MODE |
SYNCHRONOUS WITH PC |
| STOCK TEMPERATURE |
(-40°C~+ 85°C) |
| WORKING TEMPERATURE |
(-20°C~+ 50°C) |
| OPERATING HUMIDITY |
10-90%RH |
| PROTECTION RATING |
IP 65 |
| FLIGHT CASE PACKAGING (4 IN 1) |
66 X 49 X 80 |
| GROSS WEIGHT |
61 KG |
P4.81 Outdoor LED Display
Make a statement with our P4.81 outdoor LED display, delivering outstanding visual clarity and brightness. Shielded by IP65 defense and wide temperature tolerance, it’s constructed to withstand outdoor elements, ensuring uninterrupted operation. Its versatile connectivity options and high color and grayscale capabilities make it perfect for outdoor advertising, event signage, and transportation hubs. Experience vibrant and detailed visuals that capture attention outdoors.
Additional information
| Screen Resolution |
360000 Pixels |
|---|---|
| LED BRANDLED |
KING LIGHT |
| LAMP MODEL |
SMD 1921 |
| LED Configuration |
1R1G1B |
| Pixel Pitch |
4.81 mm |
| Physical Density |
43403 PIXEL/M2 |
| MODULE SIZE |
288 x 288 mm |
| Module Resolution |
75 x 75 Dots |
| Drive Mode |
1/15S |
| Cabinet Configuration |
576mm x 576 mm x 85 mm |
| Cabinet Resolution |
120 x 120 Dots |
| cabinet weight |
9.8 kgs |
| Module quantity |
4 pcs |
| Material Of Cabinet |
Die cast aluminum alloy |
| color of cabinet |
black (can be changed free) |
| Brightness |
≥4000 cd/m2 |
| view angle |
120°(h),110°(v) |
| Gray scale |
≥16bits/4096 level |
| color capacity |
1.67 billion |
| Maximum power consumption |
500 W/m2 |
| Average power consumption |
200/m2 |
| Operating Power Source |
220V,50-60Hz |
| recieving card |
NOVA STAR , A5S-N |
| POWER SUPPLY BRAND |
RONGTRONIC |
| REFRESH RATE |
≥3840 Hz |
| Drive IC |
ICN 3153/SM 16380 |
| Service |
REAR |
| MODULE CAONNECTION |
SOLID CONNECTION |
| CONTROL MODE |
SYNCHRONOUS WITH PC |
| STOCK TEMPERATURE |
(-40°C~+ 85°C) |
| WORKING TEMPERATURE |
(-20°C~+ 50°C) |
| OPERATING HUMIDITY |
10-90%RH |
| PROTECTION RATING |
IP 65 |
| FLIGHT CASE PACKAGING (4 IN 1) |
66 X 49 X 80 |
| GROSS WEIGHT |
61 KG |
