WASH SPOT 150

The WASH SPOT 150, the newest addition to our Club Series lineup. At just 150 watts, it stands as the smallest wash fixture in the series, yet packs a punch with its impressive performance.

Designed with installations in clubs, restaurants, and similar venues in mind, the WASH SPOT 150 offers unparalleled versatility and convenience. Its compact size makes it ideal for spaces where real estate is limited, while its powerful output ensures vibrant and dynamic lighting effects that elevate any atmosphere.

Whether you’re looking to wash the dance floor with pulsating colors or highlight key architectural features with precision, the WASH SPOT 150 delivers exceptional results. With its targeted design and robust features, it’s the perfect lighting solution for venues seeking to enhance their ambiance and captivate audiences.

Description

The WASH SPOT 150, the newest addition to our Club Series lineup. At just 150 watts, it stands as the smallest wash fixture in the series, yet packs a punch with its impressive performance.

Designed with installations in clubs, restaurants, and similar venues in mind, the WASH SPOT 150 offers unparalleled versatility and convenience. Its compact size makes it ideal for spaces where real estate is limited, while its powerful output ensures vibrant and dynamic lighting effects that elevate any atmosphere.

Whether you’re looking to wash the dance floor with pulsating colors or highlight key architectural features with precision, the WASH SPOT 150 delivers exceptional results. With its targeted design and robust features, it’s the perfect lighting solution for venues seeking to enhance their ambiance and captivate audiences.

Additional information
Lamp type

150W

Lens

high-precision optical lens

Beam Angle

16 °

COLOR SYSTEM

7 colors + white light

PATTERN

7 patterns + white circles

MOVING PARAMETER

Angle: Pan 540", Tilt 270"
PAN and TILT adopt an electro-optic reset system Which automatically resets the parameters if any change is caused by accident.

EFFECT EQUIPMENT

Independent frost soft effect, Mechanical linear 0-100% dimming, Fast strobe, multiple strobe effects, (Pulse/asynchronous/synchronous/ slow-medium- fast at random) Prism: 3 prisms

CONTROL AND PROGRAMMING

Control channel: 16CH / 18CH
Control Mode: Standard DMX512 protocol, RDM (Optional), Auto Run, Sound
DMA interface: RJ45 network port, XLR port
Menu display: 16 million pixels LCD
The menu display can be rotated 180 degrees.

ELECTRONIC CONTROL TECHNOLOGY

Intelligent fan control
Electronic sensor detection
DMX control monitor
X/Y two-phase motor drive
Query by LCD screen

POWER SUPPLY

AC100-240V 50/60Hz
Consumption: 150W

PHYSICAL

Product dimensions: 19.5 x 19.5 x 34 CM
Net weight: 3.7KG
Gross weight: 22KG
Cardboard packing (4 in 1): 57 X 38.5 X 60CM

IP RATING

IP20
