| Pixel Density |
250000 |
|---|---|
| MODULE SIZE |
320 x 160 X 15 mm |
| MODULE RESOLUTION |
160 x 80 |
| SCREEN THICKNESS |
76 mm (WITHOUT COVERED EDGE) / 80 mm (WITH COVERED EDGE) |
| Scan Mode |
1/40 |
| LED package |
SMD 1515 |
| Brightness |
600-800 nits |
| Gray scale |
12-14 bits |
| Refresh Rate |
3840 hz |
| BRIGHTNESS UNIFORMITY |
>98% |
| Contrast Ratio |
5000:1 |
| viewing angle |
H: 160 , V: 160 |
| Colour Temperature: |
6000-9000 K |
| SCREEN WEIGHT |
25KG/SQM |
| MAINTENANCE |
FRONT |
| IP Rating |
IP 30 |
| WORK VOLTAGE |
220V,50-60Hz |
| Max/Avg Power Consumption |
<720 w/m2 / <240w/m2 |
| Storage Temperature & Humidity |
-20C ~ 50C & 10-60% RH |
| WORKING TEMPERATURE & Humidity |
-20C ~ 55C & 10-80% RH |
| Installation |
MOUNTING / STACKING |
