| LED BRAND |
KING LIGHT |
|---|---|
| LAMP MODEL |
SMD 1921 |
| LED Configuration |
1R1B1G |
| Pixel Pitch |
P4 |
| Pixel Density |
62500 |
| MODULE SIZE |
320 x 160 mm |
| Scan Rate |
1/10 |
| Cabinet Dimension |
960 x 960 x 120 mm |
| Cabinet Resolution |
80 X 40 mm |
| cabinet weight |
40 kg |
| Module quantity |
18 pcs (3 X 6 pcs) |
| Material Of Cabinet |
Steel Iron Cabinet |
| color of cabinet |
Black ( can be changed free ) |
| Brightness |
4000 – 5000 nits |
| view angle |
140° (h), 120° (v) |
| Gray scale |
14 Bits |
| Contrast Ratio |
5000:1 |
| Maximum power consumption |
<1000w/m2 / <300w/m2 |
| Operation power source |
220V,50-60Hz |
| recieving card |
NOVA STAR , A5S-N |
| Installation |
Mounting/Stacking/Hanging |
| Refresh Rate |
1920 / 3840 Hz |
| Service |
REAR (Optional from front) |
| Colour Temperature: |
6000-9000 K |
| Storage Temperature & Humidity |
(-20℃～50℃) & 10-60 % RH |
| WORKING TEMPERATURE & Humidity |
(-20℃～55℃) & 10-90 % RH |
| IP Rating |
IP 65 |
